5X7 LED Dot Matrix Display
Common anode or cathode
a, Black or grey surface with white diffuse
b, Colors: red(640nm),yellow green (572nm),pure green(525nm),yellow(590nm),blue(430nm), pure blue(470nm).
c, Digit height: 4.2"
d, Customized requirements can meet.
Application
a. Digital information
b. LED message display board.
c. Instruments, digital clock & toys
d. Mark, domestic appliance and other household electrical appliances.
e. The image display and instructions
f. Customized LED panel displays.
g. General use.
| 5×7 Dot Matrix Display |
| Digit Size | Part No. | Chip | Ifp=40mA 1/8Duty | Drawing No. |
| Common Anode | Common Cathode | Material/Emitted Color | Wave Length λD(nm) | VF (V) | Iv.Typ. Per.Dot. (mcd) |
| Typ. |
| 2.1inch ￠5.0 5×7 | BM0-5742UB-A111 | BM0-5742UB-C111 | InGaN/SiC Blue Chip | 465 | 3.2 | 12 | MD-09 |
| BM0-5742TB-A111 | BM0-5742TB-C111 | InGaN/Al2O3 Blue Chip | 465 | 3.1 | 30 |
| BM0-5742PG-A111 | BM0-5742PG-C111 | InGaN/SiC Pure Green Chip | 525 | 3.2 | 30 |
| BM0-5742GU-A111 | BM0-5742GU-C111 | Gap/Gap Yellow Green Chip | 570 | 2.15 | 3.8 |
| BM0-5742UG-A111 | BM0-5742UG-C111 | AlInGaP/GaAs Yellow Green Chip | 570 | 2.1 | 12 |
| BM0-5742HY-A111 | BM0-5742HY-C111 | GaAsP/GaP Yellow Chip | 590 | 2.1 | 2.4 |
| BM0-5742UY-A111 | BM0-5742UY-C111 | AlGaInP/GaAs Yellow Chip | 590 | 2.05 | 24 |
| BM0-5742YO-A111 | BM0-5742YO-C111 | AlGaInP/GaAs Orange Chip | 605 | 2.05 | 24 |
| BM0-5742HO-A111 | BM0-5742HO-C111 | GaAsP/GaP Orange Chip | 625 | 2 | 2.4 |
| BM0-5742UR-A111 | BM0-5742UR-C111 | AlGaInP/GaAs Red Chip | 630 | 1.95 | 13 |
| BM0-5742SR-A111 | BM0-5742SR-C111 | AlGaAs/GaAs Red Chip | 643 | 1.85 | 8.4 |
